Jaxen CNC Operating Guide Visit Jaxen's homepage here. Page is under construction by colinl. Work in progress. This page documents procedures on Jaxen that should be followed when doing any projects. Purposes of this guide: * keeping users safe * prevent damage to the machine

Jaxen CNC Electrical Documentation Visit Jaxen's homepage here. All the controller hardware is located in an electrical panel on the wall behind the mill. [NDR-480-48] ---------- 1. Power Supplies There are four Mean Well power supplies: * NDR-480-48 (x2): Provide 48V, 10A DC to the stepper/servo drivers (blue modules marked Motor Z/A and Motor X/Y).

Jaxen - CNC Milling Machine Jaxen is the most powerful CNC mill at VHS, capable of milling steels and other metals harder than aluminum and brass. As of 2026 March, it is being prepared for wider member use. This is the homepage for Jaxen. Wiki pages for Jaxen:

Grizzly G0463 Mill "Gage" “Gage” was the half-built CNC mill that used to be in the Northeast corner of CNC land. Due to similarity to Jaxen, and the fact that it was not operational (ever?), it was disposed and sold. The CNC mill Jaxen is now in it's place! Many parts and equipment for Gage is compatible with Jaxen.
